SPECIFICATIONS
PVC FRAME PROFILE reinforced with steel insert
– Made in Europe;
– 6 chambers profile;
– 2 Synthetic rubber seal;
– Class A+ energy efficiency;
– Profile width 70 mm (2 3/4″);
– Heat resistance W/SqM/C = 1.20;
– Heat resistance Btu/Hour/SqF/F = 0.21;
– R value = 4.76;
PVC PROFILE TECHNICAL SPECS
Frame Thickness (FT)– 70 mm (2 3/4″)
Frame High (FH) – 68 mm (2 11/16″)
Frame and Sush High (combined) (FSH) – 118 mm (4 21/32″)
DOUBLE GLAZED Insulated Glass Unit
Our windows can be supplied with
Double or Triple Insulated glass unit (IGU)
Double IGU formula is: 4i-16Ar-4, meaning:
4 mm LowE glass – 16 mm space filled with Argon gas – 4 mm glass
IGU thickness: 24 mm
Heat insulating Btu/Hour/SqF/F = 0.27
R value = 3.7
TRIPLE GLAZED Insulated Glass Unit
Our windows can be supplied with
Double or Triple Insulated glass unit (IGU)
Triple IGU formula is: 4i-10Ar-4-10Ar-4, meaning:
4 mm LowE glass – 10 mm
Argon gas space – 4 mm glass – 10 mm
Argon gas space – 4 mm glass
IGU thickness: 32 mm
Heat insulating Btu/Hour/SqF/F = 0.19
R value = 5.1
WINDOW OPERATION
Our windows are operated with One Handle located on the side.
There are 4 operating positions:
1. Position Vertically Down: FULLY CLOSED
2. Position Horizontal: OPENED INSIDE
3. Position Angled up: PASSIVE VENTILATION
4. Position Vertically Up: TILTED INSIDE
BLUEPRINT explanation
REMEMBER:
You look at the window drawing FROM INSIDE (always)
Legend:
1. Operating handle
2. Hinges
3. Triangle Top shows the OPEN Direction (towards inside)
4. Triangle Top shows the TILT Direction (towards inside)
5. Width (in)
6. Height (in)
7. IGU Formula
